Dahua Full Color 5MP 2.8MM-HDW1509TLQP-A-LED

5MP HDCVI camera Dahua DH-HAC-HDW1509TLQP-A-LED (3.6 mm)

• Dahua DH-HAC-HDW1509TLQP-A-LED is ideal for ensuring security in open spaces and outdoor facilities. The body is made of metal and has an IP67 protection rating, which guarantees reliable protection from dust and moisture (RH95% Max), and also withstands extreme temperatures from -40 ° C to + 60 ° C.
• The camera is equipped with a fixed lens with a focal length of 3.6 mm and a viewing angle of 88°. The device is based on a 5-megapixel CMOS matrix with a resolution of 2880×1620 pixels.
• LED backlighting with Full-color technology allows you to illuminate an area at a distance of up to 20 meters, while maintaining a color image even in low light, automatically turning on when the built-in light sensor is activated.
• The built-in microphone allows you to record video with sound, which allows you to record events at the site in more detail and quickly respond to incidents.
• Dahua DH-HAC-HDW1509TLQP-A-LED supports multiple video formats: HDCVI, CVBS, AHD and TVI, making it compatible with various DVR, HDCVI and HD-TVI digital video recorders.

Characteristics

• Matrix: 5 MP
• Min. sensitivity: 0.001 lx/F1.0
• Shutter speed: 1/3 – 1/100000 s
• Noise Reduction (DNR): 3D
• WDR: 120 dB
• BLC: Supports
• HLC: Supports
• Axle adjustment: Pan: 0- 360°, Tilt: 0° – 78°, Roll: 0° – 360°
• Viewing angles: H: 88; W: 46°; D: 104°
• Focal length: 3.6 mm
• Aperture: F1.0
• Backlight type: LED
• Backlight range: 20 m
• Frame rate (main stream): 5MP; 4MP; 1080P 25 fps
• Audio interfaces: built-in microphone
• Object detection: 80 m
• Observation of the object: 32 m
• Object recognition: 16 m
• Object identification: 8 m
• Basic processing functions:
• 8 masking zones: Permission support
• 5M (2880×1620); 4M (2560×1440); 1080p (1920×1080); 960H (960×576/960×480)
• Type (form factor): Dome
• Recording: To the hard disk HDD
• Number of diodes: 1
• Lens mount: M12
• Purpose: For home, For apartment, For shop, For office, For premises
• Peculiarities: High Definition, Sound Recording, Microphone, Video Analytics,
• Focusing distance: 1.6 m
• Viewing angle: 88°
• Installation: Outdoor, Indoor
• Sensitivity: 0.001 lx/F1.0
• Nutrition: 12VDC
• Power consumption: 4.4 W
• Operating temperature: –40 °C – +55 °C
• Degree of protection: IP67
• Dimensions: φ97 × 92 mm
• Weight: 240 g
